| Code | No-load Speed mm/s | Force(N) | Force(N) |
| 12V | 24V | ||
| A | 5 | 180 | 180 |
| B | 9.5 | 90 | 90 |
| C | 15 | 60 | 60 |
| D | 30 | 30 | 30 |
| E | 30 | 20 | 20 |
| Voltage: 12/24V DC |
| Max Load: 180 N |
| Max Stroke: 10~150mm Customizable |
| Working Frequency: 10% |
| No-load Speed： 5~30mm/s |
| Protection Level: IP54 |
| Operating Temperature: -20℃~60℃ |
| Noise Level: ≤50 dB |
| Controller Options: Wired controller, wireless controller, customized controller. |
| Built-in Limit Switches: Non-adjustable |
| Code | No-load Speed mm/s | Force(N) | Force(N) |
| 12V | 24V | ||
| A | 5 | 180 | 180 |
| B | 9.5 | 90 | 90 |
| C | 15 | 60 | 60 |
| D | 30 | 30 | 30 |
| E | 30 | 20 | 20 |
