Prioritize meeting thrust requirements first, then no-load/full-load speed.
Selection Criteria: Prioritize meeting thrust requirements first, then no-load/full-load speed.
Self-locking Optimization: To ensure self-locking force, select specification codes with smaller lead values.
Speed Note: The full-load speed of this actuator is approximately 70% of its no-load speed (marked in the table).
Data Accuracy: Table values are measured at room temperature; deviations up to ±10% may occur due to machining and assembly tolerances.
| Voltage: 12/24V DC |
| Max Load: 800 N |
| Working Frequency: 10% |
| No-load Speed： 5~36mm/s |
| Protection Level: IP67 |
| Operating Temperature: -20℃~60℃ |
| Noise Level: ≤50 dB |
| Controller Options: Wired controller, wireless controller, customized controller. |
| Built-in Limit Switches: Non-adjustable |
| Code | Lead(mm) | Speed(mm/s) | Max Load(N) | Self-locking Force max(N) | No-load Current(A) | Full-load Current(A) | |||
| No-load | Full-load | 12V | 24V | 12V | 24V | ||||
| A1 | 2 | 5 | 3.5 | 850 | 900 | 0.3 | 0.2 | 1.3 | 0.8 |
| B1 | 3 | 7 | 5 | 800 | 850 | ||||
| C1 | 4 | 10 | 7 | 600 | 650 | ||||
| D1 | 9 | 22 | 15 | 300 | 350 | ||||
| E1 | 15 | 36 | 25 | 200 | 250 | ||||
